1.Introduction:

• Digital LCD Viscometer, applies stepping motor based on 16-bytes microcomputer processor, with blue screen TFL-LCD. with even rotate speed, distinctive keystrokes, programming, and alarming system, and also it’s easy to use.
• Displayer tells directly viscosity, rotary speed, temperature, centesimal torsion, serial number of the spindle and maxim viscosity that can be measured at present rotary speed of the spindle used.
• Master control board and Subdivides the actuation board completely to use pastes the piece technique.
• The circuit is designed by the most advanced microcomputer processor in the world, thus the structure is reasonable and compact.

•
  The full scale and levels of lineal measure are measured and adjusted through a PC interface, whose measuring capability is up to the advanced standards of similar types abroad.

2.Specification:

Display: English

Power supply: AC110V-AC220V
Measuring Range cp(mPa·s): 1-2000k(mPa·s)
Speed Range(RPM): 0.3RPM 0.6RPM 1.5RPM 3RPM 6RPM 12 RPM 30 RPM 60 RPM(Have no wheel gear arouse)
Number of Spindles :4 kinds(The 0th rotor for select and match)
Accuracy: ±2.0%
Repeatability: 0.5%
Voltage: 220V±10V

Applications:

Inks, Latex, adhesive (solvent base)
Polymer solutions ,oils, paints and coatings
Solvents, cosmetics, dairy products
Pharmaceuticals, Juices, etc.
