AC WITHSTANDING

Output-Voltage Range

0.10kV~ 5.00kV ac

Output-Voltage Resolution

10V

Output-Voltage Accuracy

± (1.5% of setting + 2 counts) with no load

Maximum Rated Load

100 VA (5kV/20mA)

Maximum Rated Current

20mA (0.5kV < V ≦ 5kV)

5mA (0.1kV ≦ V≦ 0.5kV)

Output-Voltage Waveform

Sine wave

Output-Voltage Frequency

50 Hz / 60 Hz selectable

Voltage regulation

± (1.5% + 2 counts) [full load → no load]

Voltmeter Accuracy

± (1.5% of reading + 2 counts)

Current Measurement Range

0.01mA~20.0mA

Current Best Resolution

0.01mA / 0.1mA

Current Measurement Accuracy

±(2.0% of reading + 10 counts) when HISET < 1.00mA

±(2.0% of reading + 3 counts) when HISET ≧ 1.00mA

Current Judgment Accuracy

±(3.0% of setting + 10 counts) when HISET < 1.00mA

±(3.0% of setting + 3 counts) when HISET ≧ 1.00mA

Window Comparator Method

Yes

ARC Detect

Yes

RAMP (Ramp-Up Time)

0.1s fixed

TIMER (Test Time)

OFF, 1s~180s

GND

ON
